A&A Melters
A-500
The A-500 is our largest unit, with a 500 Gallon capacity its the biggest Rubberized Asphalt Melter on the market.
A&A MELTERS
A-500
The A-500 is our largest unit, with a 500 Gallon capacity its the biggest Rubberized Asphalt Melter on the market.
- Stainless steel fire tubes come standard.
- Front mounted burners.
- Hassle free Material spout at rear.
- Dual loading doors.
- Patented “air-jacketed design”
- No more messy heat transfer oils.
- Heats material in as little as 90 minutes.
- Electric brakes come standard.
- Tandem axle standard.
- Heavy Duty trailer mounted lifting lugs Standard
A&A MELTERS
Specification
| Specification | Detail |
|---|---|
| Heat Transfer Oil | None Required |
| Fire Tubes | 5″ sch 80 Stainless Steel Pipe |
| Capacity | 480 US Gallons |
| Agitator | Honda 9.0 H.P. Air-Cooled Engine, 110 Volt Electric or Optional Diesel Engine |
| Overall Dimensions | L-198″ W-80″ H-70″ 4,800 lbs |
| Burner | Adjustable Liquid Propane 2 × 750,000 BTU or Optional Beckett Diesel Burners |
| Temperature Controls | Optional Optional |
| Inner Shell | 1/4″ Rolled Steel |
| Outer Shell | 3/16″ Rolled Steel |
| Insulated Jacket | 1″ Super High Temp. plus 2″ High Temp. |
| Suspension 4″ Drop Axle | Tandem Axle — 2 × 6000 lb Axles |
| Brakes | Electric Standard |
| Tow Hitch | As ordered c/w safety chain |
| Shipping Weight | 4,800 lbs |
| Pump | 2″ Viking Optional |
| Horizontal Wand Pumping System | Optional |
| Tires | 4 × 8.00 × 16″ 10 Ply Rating |
| Chassis | 6″ Steel Channel |
| Tandem Axle | Standard |
| Heated Material Output | |
| Efficiency | 85.0% |
| Heat Up Time | 90 mins |
| Material Capacity | 480 US Gallons — Output approx. 400 gal/hr |
