A&A Melters

A-110 Electric Melter

100% Electric Rubberized Asphalt Melters

Available in 60, 100 & 200 Gallon Models

A&A MELTERS

A-110 Electric

  • No open or enclosed flame on rooftops.
  • Built to match the speed and efficiency of our propane & diesel fired melters
  • No gas, propane or diesel needed on the roof.
  • Very precise control of heat distribution by means of computerized controllers controlling many parameters such as heating elements. (% of power to rising temperature)
  • Safety features include high limit controller which shut the machine down if temperature rises above factory preset. (Material manufacturers recommended temp.)
  • All electrical components are Watlow products which are UL and CSA approved, such as our tubular flange electric heaters.
  • High limit controllers are factory mutual approved. (Used in New York City with vent less deep fat fryers)
  • All electrical components are protected with proper breakers and installed by a qualified electrician.
  • Machines are heavy duty and compact as to get on rooftops easily.
  • Material agitators are electrical powered and require no fuel to run them.
  • Components are designed with forward thinking capabilities. (Alarm and a wireless temperature monitoring communications system)
  • Because the Electric melter does not use any fossil fuels it has a far less negative impact on the environment than any other melter on the market today.

Our 100% Electric melters come equipped with electric heater elements, electric drive system for the agitator and a factory programmed, easy to use temperature regulator and safety system .

Our electric melters run on 480 Volt 3 phase power, which can be made available via an existing on site hook up or through the rental or a portable/towable generator set. Contact us for details concerning power usage and rental options in your area.

A&A MELTERS

Specification

Specification Detail
Capacity 100 US Gallons
Agitator 110 V Electric
Overall Dimensions (Melter Only) L-91″   W-34″   H-45″   1,500 lbs
Burner 480V, 3PH 35 Amp Total (2 × 17.5 Amp 5″ 12 KWH Flanged Electric Elements)
Temperature Controls Comes standard with all safety options installed Standard
Inner Shell 3/16″ Rolled Steel
Outer Shell 1/8″ Rolled Steel
Insulated Jacket 1/2″ Super High Temp. plus 2″ High Temp. Fiberglass
Pump 1 1/2″ Electric Viking Pump Optional
Optional Trailer (w/ Melter mounted) L-146″   W-71″   H-71″   1,775 lbs Optional
Brakes Electric Standard
Tow Hitch As ordered c/w safety chain
Shipping Weight (Melter only) 1,500 lbs
Shipping Weight (Trailer only) 275 lbs
