100% Electric Rubberized Asphalt Melters
Available in 60, 100 & 200 Gallon Models
Our 100% Electric melters come equipped with electric heater elements, electric drive system for the agitator and a factory programmed, easy to use temperature regulator and safety system .
Our electric melters run on 480 Volt 3 phase power, which can be made available via an existing on site hook up or through the rental or a portable/towable generator set. Contact us for details concerning power usage and rental options in your area.




| Specification | Detail |
|---|---|
| Capacity | 60 US Gallons |
| Agitator | 110 V Electric |
| Overall Dimensions (Melter Only) | L-61″ W-34″ H-45″ 1,250 lbs |
| Burner | 480V, 3PH 20 Amp Total (2 × 4″ 12 KWH Flanged Electric Elements) |
| Temperature Controls | Comes standard with all safety options installed Standard |
| Inner Shell | 3/16″ Rolled Steel |
| Outer Shell | 1/8″ Rolled Steel |
| Insulated Jacket | 1/2″ Super High Temp. plus 2″ High Temp. Fiberglass |
| Shipping Weight (Melter only) | 1,200 lbs |
