Introducing our newly designed Air-Jacket Mastic Melter, designed for melting repair mastics & aggregate filled patching products used for repairing Concrete & Asphalt.
Introducing our newly designed Air-Jacket Mastic Melter, designed for melting repair mastics & aggregate filled patching products used for repairing Concrete & Asphalt. Implementing the same high standard of quality and durability that has been used in producing our line of Hot Rubber Melter for the past 25 years. These units feature a full sweep agitator and Automatic temperature controls ensure material is kept within a specific temperature. Our unique Air-jacketed design allows for exceptionally quick heating of material without some of the problems often associated with typical Oil Jacketed units.




| Specification | Detail |
|---|---|
| Heat Transfer Oil | None Required |
| Fire Tubes | 5″ Sch 80 Stainless Steel Pipe |
| Capacity Custom Sizes Available | 240 US Gallons |
| Hydraulic Agitator w/ Auto Shut Off | 23 HP Diesel |
| Overall Dimensions | L-198″ W-74″ H-70″ |
| Burners | Adjustable Liquid Propane or Optional Beckett Diesel Burners |
| Temperature Controls | Standard |
| Inner Shell | 1/4″ Rolled Steel |
| Outer Shell | 3/16″ Rolled Steel |
| Insulated Jacket | 1″ Super High Temp. plus 2″ High Temp. |
| Suspension 4″ Drop Axle | Tandem Axle — 2 × 3500 lb. Axles |
| Tires | 4 × 8.00 × 15″ |
| Tandem Axle | Standard |
| Chassis | 4″ Steel Channel |
| Brakes | Electric Standard |
| Tow Hitch | As ordered c/w Safety Chains (2) |
| Shipping Weight | 3,500 lbs |
| Key Features | |
|
|
